LK SIN CA*MODELO OEM BULK SIN CAJA*

Las tarjetas madre comerciales ASUS Pro ofrecen características mejoradas para suavizar sus operaciones de TI, que incluyen protección integral del sistema, estabilidad y confiabilidad las 24 horas del día, los 7 días de la semana y un paquete de administración mejorado para una personalización más fácil. Conocida como la marca de tarjetas madre más grande y conocida del mundo, ASUS ofrece un servicio posventa de clase mundial y una disponibilidad garantizada a largo plazo para maximizar su inversión durante el ciclo de vida del producto y ofrece una solución de alta calidad optimizada para TCO para su negocio necesidades informáticas.

Tarjeta madre de negocios AMD Micro-ATX A320 con USB 3.1 Gen 2 tipo C, WiFi, seguridad, confiabilidad y capacidad de administración mejoradas para la reducción del TCO
Tecnología de recuperación de BIOS automática exclusiva de ASUS para la recuperación automática del BIOS del sistema desde una copia de seguridad verificada
Pueto LPC dedicada y tarjeta de depuración con pantalla LCD para una resolución de problemas más rápida
Registro de eventos para capturar y administrar información detallada del sistema
Recubrimiento innovador resistente a la humedad para proteger la placa base de entornos hostiles
Kit de BIOS comercial para que la personalización sea más rápida y eficiente.

MAS ESPECIFICACIONES!!

CPU
AMD AM4 Socket for 3rd/2nd/1st Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/Athlon™ with Radeon™ Vega Graphics/7th Generation A-series/Athlon X4 Processors
Supports CPU up to 8 cores
* Refer to www.asus.com for CPU support list

Chipset
AMD A320
Memoria
3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
2 x DIMM, Max. 32GB, DDR4 2933/2666/2400/2133 MHz Un-buffered Memory
AMD 7th Generation A-Series/Athlon X4 Processors
2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Un-buffered Memory
Dual Channel Memory Architecture
ECC Memory (ECC mode) support varies by CPU.
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.

LISTA DE PROCESADORES COMPATIBLES:

CPU Desde PCB Desde BIOS Nota
A10-9700 (AD9700AGM44AB, 3.5GHz, 4C, L2:2M, 65W,rev.A1,AM4) ALL 0217 GO
A10-9700E (AD9700AHM44AB, 3.0GHz, 4C, L2:2M, 35W,rev.A1,AM4) ALL 0217 GO
A12-9800 (AD9800AUM44AB, 3.8GHz, 4C, L2:2M, 65W,rev.A1,AM4) ALL 0217 GO
A12-9800E (AD9800AHM44AB, 3.1GHz, 4C, L2:2M, 35W,rev.A1,AM4) ALL 0217 GO
A6-9400 (AD9400AGM23AB, 3.4GHz, 2C, L2:1M, 65W,rev.A1,AM4) ALL 0208 GO
A6-9500 (AD9500AGM23AB, 3.5GHz, 2C, L2:1M, 65W,rev.A1,AM4) ALL 0217 GO
A6-9500E (AD9500AHM23AB, 3.0GHz, 2C, L2:1M 35W,rev.A1,AM4) ALL 0217 GO
A6-9550 (3.8GHz, 2C, L2:1M, 65W,rev.A1) ALL 0806 GO
A8-9600 (AD9600AGM44AB, 3.1GHz, 4C, L2:2M, 65W,rev.A1,AM4) ALL 0217 GO
Athlon 200GE (3.2GHz,35W,L3:4M,2C) ALL 4011 GO
Athlon 200GE (3.2GHz,35W,L3:4M,2C,B0) ALL 0402 GO
Athlon 200GE(Raven-2) (3.2GHz,35W,L3:4M,2C) ALL 0402 GO
Athlon 220GE (3.4GHz,35W,L3:4M,2C) ALL 0208 GO
Athlon 220GE(Raven-2) (3.4GHz,35W,L3:4M,2C,B0) ALL 0402 GO
Athlon 240GE (3.5GHz,35W,L3:4M,2C) ALL 0208 GO
Athlon 240GE(Raven-2) (3.5GHz,35W,L3:4M,2C,B0) ALL 0402 GO
Athlon 3000G (3.5GHz,35W,L3:4M,2C) ALL 2201 GO
Athlon PRO 300GE (3.4GHz,35W,L3:4M,2C) ALL 1805 GO
Ryzen 3 1200(3.1GHz,65W,L3:8M,4C,rev:B1) ALL 0217 GO
Ryzen 3 1200AF (3.1GHz,65W,L3: 8M, 4C) ALL 1805 GO
Ryzen 3 1300X(3.5GHz,65W,L3:8M,4C,rev:B1) ALL 0217 GO
Ryzen 3 2200G(3.5GHz,65W,L3:4M,4C) ALL 3203 GO
Ryzen 3 2200GE(3.5GHz,45~65W,L3:6M,4C) ALL 3203 GO
Ryzen 3 3100 (3.6GHz, 65W, L3:16M,4C) ALL 1607 GO
Ryzen 3 3200G (3.6GHz,45-65W,L3:4M,4C) ALL 0602 GO
Ryzen 3 3200GE (3.3GHz, L3:4M,4C) ALL 1805 GO
Ryzen 3 3300X (3.8GHz, 65W, L3:16M,4C) ALL 1607 GO
Ryzen 3 PRO 1200(3.1GHz,65W,L3:8M,4C,rev:B1) ALL 0217 GO
Ryzen 3 PRO 1300(3.4GHz,65W,L3:8M,4C,rev:B1) ALL 0217 GO
Ryzen 3 PRO 3200G (3.6GHz,L3:4M,4C) ALL 1805 GO
Ryzen 3 PRO 3200GE (3.3GHz,L3:4M,4C) ALL 1805 GO
Ryzen 5 1400(3.2GHz,4C,L3:8M,65W,rev:B1) ALL 0217 GO
Ryzen 5 1500X(3.5GHz,65W,L3:16M,4C,rev:B1) ALL 0217 GO
Ryzen 5 1600(3.2GHz,6C,L3:16M,65W,rev:B1) ALL 0217 GO
Ryzen 5 1600AF(3.2GHz,6C,L3:16M,65W,rev:B1) ALL 1805 GO
Ryzen 5 1600X(3.5GHz,95W,L3:16M,6C,rev:B1) ALL 0217 GO
Ryzen 5 2400G(3.6GHz,45~65W,L3:4M,4C) ALL 3203 GO
Ryzen 5 2400GE(3.2GHz,35W,L3:4M,4C) ALL 3203 GO
Ryzen 5 2600(3.4GHz,6C,L3:16M,65W,B2) ALL 3803 GO
Ryzen 5 2600X(3.6GHz,6C,L3:16M,95W,B2) ALL 3803 GO
Ryzen 5 3350G (3.6GHz,65W,L3:4M,4C) ALL 2201 GO
Ryzen 5 3400G (3.7GHz,45-65W,L3:4M,4C) ALL 0602 GO
Ryzen 5 3400GE (3.3GHz,L3:4M,4C) ALL 1805 GO
Ryzen 5 3500 (3.6Ghz,65W,L3:16M,6C) ALL 0602 GO
Ryzen 5 3500X (3.5Ghz,65W,L3:32M,6C) ALL 1607 GO
Ryzen 5 3600 (3.6GHz,65W,L3:32M,6C,B0) ALL 0602 GO
Ryzen 5 3600X (3.8GHz,95W,L3:32M,6C,B0) ALL 0602 GO
Ryzen 5 3600XT (3.8GHz, 95W,L3:32M,6C) ALL 1822 GO
Ryzen 5 PRO 1500(3.5GHz,65W,L3:16M,4C,rev:B1) ALL 0217 GO
Ryzen 5 PRO 1600(3.2GHz,65W,L3:16M,6C,rev:B1) ALL 0217 GO
Ryzen 5 PRO 3400G (3.7GHz,L3:4M,4C) ALL 2201 GO
Ryzen 5 PRO 3400GE (3.3GHz,L3:4M,4C) ALL 1805 GO
Ryzen 5 PRO 3600 (3.6GHz,65W,L3:32M,6C) ALL 1805 GO
Ryzen 7 1700(3.0GHz,8C,L3:16M,65W) ALL 0217 GO
Ryzen 7 1700X(3.4GHz,8C,L3:16M,95W) ALL 0217 GO
Ryzen 7 1800X(3.6GHz,8C,L3:16M,95W) ALL 0217 GO
Ryzen 7 2700(3.2GHz,8C,L3:16M,65W,B2) ALL 3803 GO
Ryzen 7 2700X(3.7GHz,8C,L3:16M,105W) ALL 3803 GO
Ryzen 7 3700X (3.6GHz,65W,L3:32M,8C,B0) ALL 0602 GO
Ryzen 7 3800X (3.9GHz,105W,L3:32M,8C,B0) ALL 0602 GO
Ryzen 7 3800XT (3.9GHz, 105W,L3:32M,8C) ALL 1822 GO
Ryzen 7 PRO 1700(3.0GHz,65W,L3:16M,8C,rev:B1) ALL 0217 GO
Ryzen 7 PRO 1700X(3.4GHz,95W,L3:16M,8C,rev:B1) ALL 0217 GO
Ryzen 7 PRO 3700 (3.6GHz,65W,L3:32M,8C) ALL 1805 GO
Ryzen 9 3900 (3.1GHz,65W,L3:64M,12C) ALL 0602 GO
Ryzen 9 3900X (3.8GHz,105W,L3:64M,12C,B0) ALL 0602 GO
Ryzen 9 3900XT (3.8GHz, 105W,L3:64M,12C) ALL 1822 GO
Ryzen 9 3950X (3.5GHz,105W,L3:64M,16C) ALL 0602 GO
Ryzen 9 PRO 3900 (3.1GHz,65W,L3:64M,12C) ALL 1805 GO
X4-940 (3.2GHz, 4C, L2:2M, 65W,rev.A1) ALL 0805 GO
X4-950 (3.5GHz, 4C, L2:2M, 65W,rev.A1,AM4) ALL 0217 GO
X4-970 (3.8GHz, 4C, L2:2M, 65W,rev.A1) ALL 0805 GO

Gráficos
Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics /Athlon™ with Radeon™ Vega Graphics /7th Generation A-Series APU
Multi-VGA output support : HDMI/RGB/DisplayPort ports
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
- Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
Maximum shared memory of 2048 MB (for iGPU exclusively)
Slots de Expansión
3rd/2nd/1st Gen AMD Ryzen™ Processors
1 x PCIe 3.0/2.0 x16 (x16 mode)
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics /7th Generation A-series/Athlon X4 Processors
1 x PCIe 3.0/2.0 x16 (x8 mode)
AMD Athlon™ with Radeon™ Vega Graphics Processors
1 x PCIe 3.0/2.0 x16 (x4 mode)
AMD A320 chipset
1 x PCIe 3.0/2.0 x1
Almacenamiento
AMD A320 chipset :
4 x SATA 6Gb/s port(s), gray,
Support Raid 0, 1, 10
LAN
Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
Datos de redes inlámbricas
Wi-Fi 802.11 a/b/g/n/ac
Bluetooth
Bluetooth® 5.0
Audio
Realtek® ALC887 8-Channel High Definition Audio CODEC
Puertos USB
AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation/ 7th Generation A-Series/ Athlon™ X4 Processors :
1 x USB 3.1 Gen 2 port(s) (Type-C, 1 at mid-board)
AMD A320 chipset :
6 x USB 3.1 Gen 1 port(s) (4 at back panel, , 2 at mid-board)
AMD A320 chipset :
4 x USB 2.0 port(s) (4 at mid-board)
Caracteristicas Especiales
ASUS Q-Design :
- ASUS Q-Slot
- ASUS Q-DIMM
Bespoke Motherboard Design & Business Focused Features :
- ASUS Self Recovering BIOS: Automatically recover BIOS update once crash happen
- ASUS Event Log: Record activities of system and provides information in BIOS
- ASUS Commercial BIOS kit: Speed up BIOS update solutionby partial BIOS design
- Anti-Moisture: Against moisture and corrosion — prolonging the life of your motherboard
- 24/7 Reliability: Tested under temperature up to 45°C and humidity up to 80% to ensure handle diverse environment
Easy Assembly Design:
- Fixed-position&Color-coded Connectors: Enable easy identification and cable-matching, speeding up the production line
- Box Headers: USB headers are box style, enabling fast connector installation and preventing pin damage
Puertos I/O Traseros
1 x PS/2 keyboard (purple)
1 x PS/2 mouse (green)
1 x D-Sub
1 x DisplayPort
1 x HDMI
1 x LAN (RJ45) port(s)
4 x USB 3.1 Gen 1 (blue)
3 x Audio jack(s)
ASUS Wi-Fi module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v5.0)
Internal I/O
1 x USB 3.1 Gen2 connector support additional 1 USB ports(20-pin, Type-C)
1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x SPI TPM header
1 x COM port(s) connector(s)
4 x SATA 6Gb/s connector(s)
1 x CPU Fan connector(s) (1 x 4 -pin)
1 x Chassis Fan connector(s) (1 x 4 -pin)
1 x 24-pin EATX Power connector(s)
1 x 4-pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s)
1 x Chassis Intrusion connector(s)
1 x Clear CMOS jumper(s)
1 x LPC Debug header
1 x Speaker connector
Accessorios
User´s manual
I/O Shield
2 x SATA 6Gb/s cable(s)
1 x Supporting DVD
1 x Wi-Fi Antenna(s)
BIOS
128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS smart recovering BIOS, ASUS Event log, ASUS Commercial Kit
Sistema Operativo
Windows® 10 64-bit
Factor de forma
mATX Form Factor
8.9 inch x 7.9 inch ( 22.9 cm x 20.3 cm ).
